Name: 3-stage Clear 7-inch Water Filter Housings Fit Standard 7"x 2.5" Cartridges
Brand: ROYOL WATER CO., LTD
SKU: RY-10H-36
Availability: InStock

Features Gallery Product Description Chat Now

Features

Specifications

Product Name: 3-stage Clear 7-inch Water Filter Housings

Material: Plastic

Connect: 1/2", 3/4", 1" Brass Port

Fit Cartridge: 7" X 2.5" : PP Sediment, UDF/GAC, CTO, PP String Filter, PP Pleated Filter Etc.

Accessories: Release Valve, O-Ring, Bracket, Screw, Filter Housing Wrench

Advantages: DIY Water Filter System, Flexible Application

Housing Capacity: 3 Filter Cartridge

Water: Tap Water

Product: Water Filter Housing

Application: Residential, Apartment Or Industrial

Type: 3-stage

Highlight:

3-stage water filter housing

7-inch clear water filter

standard 7x2.5 filter cartridges

Basic Infomation

Place of Origin: Guanggong

Brand Name: OEM/ ODM / ROYOL

Certification: CE, RoSH

Model Number: RY-10H-36

Payment & Shipping Terms

Packaging Details: Color box

Delivery Time: 10-15 work days

Payment Terms: T/T

Supply Ability: 100 pcs per day

Gallery

3-stage Clear 7-inch Water Filter Housings Fit Standard 7"x 2.5" Cartridges

Product Description

3-Stage Clear 7-Inch Water Filter Housings

Designed to fit standard 7"x 2.5" cartridges for comprehensive water filtration solutions.

Product Specifications

Key Words	3-stage Filter Housing
Material	PP
Inlet/Outlet	1", 3/4", 1/2" Brass Port
Compatible Cartridges	PP Sediment, UDF/GAC, CTO, PP String Filter, PP Pleated Filter
Optional Accessories	Release valve, O-Ring, Bracket, Screw, Filter Housing Wrench
Customization	Label / Color Box / LOGO / Color
MOQ	According to your needs - Contact US

System Overview

The ROYOL 7-inch triple filtration system features a three-stage series deep purification design that can be flexibly configured with different functional filters including PP cotton, activated carbon, and high-precision filtration elements. This comprehensive system provides multiple purification effects including dechlorination, sediment and rust removal, color and odor elimination, and colloidal impurity interception in a single integrated solution.

Key Features

Sturdy Construction: Filter housing shell is integrally injection-molded with high-quality ABS polypropylene, featuring solid workmanship and high structural strength. Pressure-resistant, impact-resistant, anti-aging, deformation-resistant, and highly durable.
Wide Application Range: Suitable for residential kitchen sink installation and light commercial water treatment needs in milk tea shops, coffee shops, and small stores. Ideal for both household and commercial applications.
Optimized Water Flow: Blue end cap made of high-toughness engineering material with well-designed fluid channels ensures low water resistance and stable flow. Shatter-resistant, pressure-resistant, and crack-proof for reliable long-term operation.
Universal Connectivity: Equipped with optional brass inlet and outlet connectors compatible with 1/2", 3/4", and 1" specifications, fitting mainstream pipeline layouts. Easy installation with excellent sealing performance to prevent water leakage.
Flexible Configuration: Supports customized filter element combinations. Filtration levels and functions can be adjusted according to regional water quality conditions and specific household/commercial purification requirements for precise water treatment.
Expandable Design: Strong compatibility for system expansion. Filter elements can be upgraded, configurations replaced, or capacity expanded as needed to adapt to evolving drinking water demands. Cost-effective for long-term use.

Technical Parameters

Operating Temperature Range	4.4℃ - 40℃ / 40℉ - 104℉
Maximum Operating Pressure	8.6 Bar / 125 psi
Threaded Inserts	Brass
Connection Sizes	1/2", 3/4", 1"
Cartridge Size Compatibility	7" x 2.5"
